Binder – Growth Chambers – Series KBW – Growth chambers with light
The BINDER climate chamber with illumination of the KBW series achieves homogeneous light distribution with its natural illumination. That allows this growth chamber to create constant lighting and temperature conditions.
Key Features
- Patented lighting system ensures homogeneous light distribution
- Flexible positioning of illumination cassettes, three different light spectra, individually selectable
- Integrated weekly program in real-time
Climate Chambers with Light for Ideal Growth Conditions
Climate chambers with light from BINDER provide the ideal growth conditions for plants and other organisms. Homogeneous light distribution encourages growth, as does the constant temperature inside the climate chambers. Natural growth conditions are replicated perfectly in the climate chambers in the KBW series from BINDER.
Alongside light in combination with a constant temperature, BINDER climate chambers with light also offer a state-of-the-art humidity control system. Air can flow uniformly within the units, even when they are fully loaded.
Climate Chambers with Light for Unique Homogeneous Light Distribution
The climate chambers operate within a temperature range of between 0 °C and 70 °C, and are equipped with several illumination cassettes that can be positioned variably and have fluorescent tubes that can be adjusted in increments. This patented light system enables unique homogeneous light distribution over the entire usable area of the growth chambers.
On that basis, BINDER climate chambers with light provide optimum growth conditions for plants and insects. They also make for practical, robust, and reliable units within the cosmetics and packaging industries as well as in hospitals. The growth chambers have controllers featuring interval and real-time programming, making them incredibly easy to use and offering the option of individual adjustments to suit any laboratory requirements.
BINDER climate chambers with light come with the »Made in Germany« seal of quality. Suitable even for challenging laboratory tasks, they are characterized by a robust and durable quality, safety, and reliability.
Technical Specifications
| Model | Housing dimensions not incl. fittings and connections W x H x D | Internal dimension W x H x D | Net weight | Interior volume |
| KBW 240 | 925 x 1465 x 800 mm | 650 x 785 x 485 mm | 202 kg | 247 L |
| KBW 400 | 925 x 1950 x 805 mm | 650 x 1270 x 485 mm | 267 kg | 400 L |
| KBW 720 | 1250 x 1925 x 890 mm | 970 x 1250 x 576 mm | 377 kg | 698 L |
Available Models
- Temperature range: 0 °C to 70 °C
- Temperature range with light: 5 °C to 60 °C
- 2 positionable illumination cassettes, each with 5 fluorescent tubes
- APT.line™ preheating chamber technology
- Adjustable fan speed
- Intuitive touchscreen controller with time-segment and real-time programming with internal data recording
- Tight-sealing inner door made of safety glass (ESG)
- Avoidance of glass corrosion by special TIMELESS coating
- 2 stainless steel racks
- Access port with silicone plug, 30 mm, left
- Class 3.1 independent temperature safety device (DIN 12880) with visual and audible temperature alarm
- Computer interface: Ethernet
- Door heating
- Temperature range: 0 °C to 70 °C
- Temperature range with light: 5 °C to 60 °C
- 3 positionable illumination cassettes, each with 5 fluorescent tubes
- APT.line™ preheating chamber technology
- Adjustable fan speed
- Intuitive touchscreen controller with time-segment and real-time programming with internal data recording
- Tight-sealing inner door made of safety glass (ESG)
- Avoidance of glass corrosion by special TIMELESS coating
- 3 stainless steel racks
- Access port with silicone plug, 30 mm, left
- Class 3.1 independent temperature safety device (DIN 12880) with visual and audible temperature alarm
- Computer interface: Ethernet
- Door heating
- Temperature range: 0 °C to 70 °C
- Temperature range with light: 5 °C to 60 °C
- 3 positionable illumination cassettes, each with 5 fluorescent tubes
- APT.line™ preheating chamber technology
- Adjustable fan speed
- Intuitive touchscreen controller with time-segment and real-time programming with internal data recording
- Tight-sealing inner door made of safety glass (ESG)
- Avoidance of glass corrosion by special TIMELESS coating
- 3 stainless steel racks
- Access port with silicone plug, 30 mm, left
- Class 3.1 independent temperature safety device (DIN 12880) with visual and audible temperature alarm
- Computer interface: Ethernet
- Door heating
KBW Installation
Key Industries
- Education & Academics
- Food & Beverage
- Pharmaceutical
- Service
Brand
With 22,000 series production machines supplied each year globally, family company BINDER is now one of the leading experts on environmental simulation chambers. For over 30 years at our German site in Tuttlingen, we have developed and produced premium products which combine superior technology, first-class advice, and exemplary service. These three factors are symbolized by the three red triangles that make up our logo – and our customers appreciate the benefits every day through the outstanding results of their work.
